Acta Ortop Mex 2023; 37 (6)
There is no difference in clinical outcomes in patients with distal Neer II and Neer V clavicle fractures treated with or without coracoclavicular augmentation systems
Hernández-Naranjo J, Vives-Barquiel M, Camacho-Carrasco M, Carreras-Castañer A, Renau-Cerrillo M, Campuzano-Bitterling B
Language: Spanish
References: 25
Page: 344-349
PDF size: 148.70 Kb.
ABSTRACT
Introduction: the use of coracoclavicular augmentation systems together with locking plates in the treatment of unstable distal clavicle fractures (Neer II and Neer V) is controversial.
Material and methods: patients with unstable distal clavicle fractures treated between 2013-2022 were retrospectively reviewed. The patients were divided into two groups: patients treated with locking plates (P group) and patients treated with locking plates and coracoclavicular augmentation systems (PCC group). Postoperative complications, modified preoperative and final coracoclavicular distance (CC), and outcomes on the Visual Analog Scale (VAS) and Quick Disabilities of the Arm, Shoulder, and Hand (Quick DASH) were recorded.
Results: 16 of 23 patients were treated with plates only, and 7 of 23 were treated with plates and coracoclavicular augmentation systems. One case showed no fracture consolidation, and there was one case of cutaneous infection. The mean final CC distance was 23.7 in the P group and 22.1 in the PCC group. The mean VAS score was 1.3 in both the P and PCC groups, while the mean Quick DASH score was 5.5 in the P group and 8.1 in the PCC group. No significant differences were found in CC distance, VAS or Quick DASH scores.
Conclusion: the use of locking plates is likely sufficient in the management of unstable distal clavicle fractures, as there were no significant differences in functional outcomes in this study when coracoclavicular augmentation systems were used together with locking plates.
REFERENCES
Sandstrom CK, Gross JA, Kennedy SA. Distal clavicle fracture radiography and treatment: a pictorial essay. Emerg Radiol. 2018; 25(3): 311-19. Available in: https://doi.org/10.1007/s10140-018-1586-y
Neer CS 2nd. Fractures of the distal third of the clavicle. Clin Orthop Relat Res. 1968; 58: 43-50. Available in: https://pubmed.ncbi.nlm.nih.gov/5666866/
Rokito AS, Zuckerman JD, Shaari JM, Eisenberg DP, Cuomo F, Gallagher MA. A comparison of nonoperative and operative treatment of type II distal clavicle fractures. Bull Hosp Jt Dis. 2002-2003; 61(1-2): 32-9. Available in: https://pubmed.ncbi.nlm.nih.gov/12828377/
Hall JA, Schemitsch CE, Vicente MR, et al. Operative versus nonoperative treatment of acute displaced distal clavicle fractures: a multicenter randomized controlled trial. J Orthop Trauma. 2021; 35(12): 660-6. Available in: https://doi.org/10.1097/BOT.0000000000002211
Kirsch JM, Blum L, Hake ME. Distal clavicle fractures: open reduction and internal fixation with a hook plate. J Orthop Trauma. Available in: 2018; 32Suppl 1: S2-S3. https://doi.org/10.1097/bot.0000000000001214
Andersen JR, Willis MP, Nelson R, Mighell MA. Precontoured superior locked plating of distal clavicle fractures: a new strategy. Clin Orthop Relat Res. 2011; 469(12): 3344-50. Available in: https://doi.org/10.1007/s11999-011-2009-5.
Kapicioglu M, Erden T, Bilgin E, Bilsel K. All arthroscopic coracoclavicular button fixation is efficient for Neer type II distal clavicle fractures. Knee Surg Sports Traumatol Arthrosc. 2021; 29(7): 2064-2069. Available in: https://doi.org/10.1007/s00167-020-06048-8.
Bezer M, Aydin N, Guven O. The treatment of distal clavicle fractures with coracoclavicular ligament disruption: a report of 10 cases. J Orthop Trauma. 2005; 19: 524-8. https://doi. org/10.1097/01.bot.0000164593.04348.e5.
Robinson CM, Bell KR, Murray IR. Open reduction and tunneled suspensory device fixation of displaced lateral-end clavicular fractures: medium-term outcomes and complications after treatment. J Bone Joint Surg Am. 2019; 101(15): 1335-41. Available in: https://doi.org/10.2106/jbjs.18.00569.
Neer CS. Fracture of the distal clavicle with detachment of the coracoclavicular ligaments in adults. J Trauma. 1963;3(2):99–110. Available in: https://doi.org/10.1097/00005373-196303000-00001.
Van der Meijden OA, Gaskill TR, Millett PJ. Treatment of clavicle fractures: current concepts review. J Shoulder Elbow Surg. 2012; 21(3): 423-9. Available in: https://doi.org/10.1016/j.jse.2011.08.053.
Zhang C, Huang J, Luo Y, Sun H. Comparison of the efficacy of a distal clavicular locking plate versus a clavicular hook plate in the treatment of unstable distal clavicle fractures and a systematic literature review. Int Orthop. 2014; 38(7): 1461-8. Available in: https://doi.org/10.1007/s00264-014-2340-z.
Fox HM, Ramsey DC, Thompson AR, Hoekstra CJ, Mirarchi AJ, Nazir OF. Neer type-II distal clavicle fractures: a cost-effectiveness analysis of fixation techniques. J Bone Joint Surg Am. 2020; 102(3): 254-261. Available in: https://doi.org/10.2106/jbjs.19.00590.
Gutman MJ, Joyce CD, Patel MS, Lazarus MD, Horneff JG. Outcomes following different fixation strategies of Neer type IIB distal clavicle fractures. Arch Bone Jt Surg. 2022; 10(2): 160-165. Available in: https://doi.org/10.22038/ABJS.2021.54472.2718.
Panagopoulos A, Solou K, Tatani I, et al. What is the optimal surgical treatment for Neer type IIB (IIC) distal clavicle fractures? A systematic review and meta-analysis. J Orthop Surg Res. 2022; 17(1): 215. Available in: https://doi.org/10.1186/s13018-022-03108-2.
Madsen W, Yaseen Z, LaFrance R, et al. Addition of a suture anchor for coracoclavicular fixation to a superior locking plate improves stability of type IIB distal clavicle fractures. Arthroscopy. 2013; 29(6): 998-1004. Available in: https://doi.org/10.1016/j.arthr o.2013.02.024.
Bishop JY, Roesch M, Lewis B, Jones GL, Litsky AS. A biomechanical comparison of distal clavicle fracture reconstructive techniques. Am J Orthop (Belle Mead NJ). 2013; 42(3): 114-8. Available in: https://pubmed.ncbi.nlm.nih.gov/23527327/
Fan J, Zhang Y, Huang Q, Jiang X, He L. Comparison of treatment of acute unstable distal clavicle fractures using anatomical locking plates with versus without additional suture anchor fixation. Med Sci Monit. 2017; 23: 5455-5461. Available in: https://doi.org/10.12659/msm.903440.
Xu H, Chen WJ, Zhi XC, Chen SC. Comparison of the efficacy of a distal clavicular locking plate with and without a suture anchor in the treatment of Neer IIb distal clavicle fractures. BMC Musculoskelet Disord. 2019; 20(1): 503. Available in: https://doi.org/10.1186/s12891-019-2892-6.
Dey Hazra RO, Blach RM, Ellwein A, Lill H, Warnhoff M, Jensen G. Additional coracoclavicular augmentation reduces revision rates in the treatment of lateral clavicle fractures as compared to angle-stable plate osteosynthesis alone. Arch Orthop Trauma Surg. 2022; 142(6): 1083-90. Available in: https://doi.org/10.1007/s00402-021-03893-1.
Tang H, Yin Y, Han Q, Xu X, Li Y. [Effectiveness of anatomical locking plate internal fixation combined with coracoclavicular ligament reconstruction for Neer type ?b distal clavicle fractures]. Zhongguo Xiu Fu Chong Jian Wai Ke Za Zhi. 2018; 32(9): 1181-6. Available in: https://doi.org/10.7507/1002-1892.201803127.
Salazar BP, Chen MJ, Bishop JA, Gardner MJ. Outcomes after locking plate fixation of distal clavicle fractures with and without coracoclavicular ligament augmentation. Eur J Orthop Surg Traumatol. 2021; 31(3): 473-9. Available in: https://doi.org/10.1007/s00590-020-02797-x
Zheng YR, Lu YC, Liu CT. Treatment of unstable distal-third clavicule fractures using minimal invasive closed-loop double endobutton technique. J Orthop Surg Res. 2019; 14(1): 37. Available in: https://doi.org/10.1186/s13018-019-1073-5.
Theodorides AA, Watkins CE, Venkateswaran B. Brachial plexus injury following the use of LARS suture passer during an open Weaver-Dunn procedure. J Shoulder Elbow Surg. 2013; 22(5): e1-5. Available in: https://doi.org/10.1016/j.jse.2013.01.009.
Sehrawat S, Bansal H, Sharma V, Farooque K. Distal third clavicle fractures treated with anatomical locking plates with or without coraco-clavicular ligament augmentation: why not an intraoperative decision? Eur J Orthop Surg Traumatol. 2023; 33(1): 199-200. Available in: https://doi.org/10.1007/s00590-021-03176-w
EVIDENCE LEVEL
III
